Hirth 2302 Series Engine Dual Ignition Carbureted
Hirth 2302 Series Engine Dual Ignition Carbureted
Couldn't load pickup availability
Price reflects complete engine package, shipping rates and customs handling fees, Allow 4 to 6 weeks delivery, engines are directly imported from Germany
2302
Power that lifts.
Performance that
lasts.
High-Performance Two-Stroke Air-Cooled Engine for Ultralight Aviation.
The 2302 engine from the 23 Series is a high-efficiency, air-cooled two-stroke engine designed specifically for ultralight aviation applications. Perfectly suited for aircraft and aerial devices weighing up to 120 kg, it delivers an impressive 50 horsepower, setting new benchmarks in the power-to-weight ratio category.
Built for performance and reliability, the 2302 engine stands out in the 50 HP class with a time between overhauls (TBO) of 1,000 hours, making it a future-ready solution for demanding flight environments.
Choose the 2302 from the 23 Series – an ultralight aircraft engine that combines power, durability, and lightweight design in one compact and proven package.
OPTIONS
- Dual ignition
- Fuel injection
- Polyflex beltreduction G23
- Electric starter
- Exhaust system (acc. to version)
- Air filter (2 pcs.)
TECHNICAL SPECIFICATION
TYPE |
|||
| Cylinder | Two-Stroke | ||
| Starting Device | Electrical starter | ||
| Running Direction | CW | ||
| Cooling | Air Cooled | ||
| Ignition | Dual | ||
| Exhaust | Normal | ||
FUEL |
|||
| Fuel | Petrol | ||
MEASUREMENTS |
mm | in |
|
| Stroke | 64,00 | 2,52 | |
| Bore | 72,00 | 2,83 | |
| Length | 446,00 | 17,56 | |
| Width | 473,00 | 18,62 | |
| Height | 450,00 | 17,72 | |
WEIGHT |
kg | lbs | |
| Weight without exhaust | 30,20 | 66,58 | |
| Weight Exhaust | 3,80 | 8,38 | |
PERFORMANCE |
kW | HP | Nm |
| Power measured (full throttle) | 32,00 | 43,52 | 46,00 |
| Power measured (best point) | 36,00 | 48,96 | 58,00 |
| Specific fuel consumption @6500rpm | (g/kWh) | 660,00 | |
| Specific fuel consumption @best point (70-80% load, 1/2 rated speed) |
(g/kWh) | 550,00 | |
| Speed | RPM | 6500 | |
TECHNICAL DRAWINGS
